Size | 1/2" to 8" |
---|---|
Thickness | 0.60 mm to 8.00 mm |
Capacity (MT per annum) | 6,00,000 (0.6 million) |
Length | 3000 mm to 8000 mm |
Grade | All national / international specifications including IS 1239 (part I), IS 1161, IS 3601,IS 4923, IS 3589, IS 9295, IS 9537 (part II), IS 4270, IS 3074 EN 10255, EN 10219 AS: 1074, ASTM A53, ASTM A795-04 |
Pipe Ends | Plain / Bevelled / Pre-grooved |
Water pipe lines | Water Mains, Plumbing, Sewerage Systems industrial water lines, Plant piping (IS 1239 (part-1) 2004, IS 3589:2001, ASTM A53-12 JIS G 3452:2010, EN 10255: 2004, EN 10217-1:2002, AS 1074:1989, ASNZ 1163-2009) |
---|---|
Agriculture and Irrigation | Farming, Deep Tube-wells & Casing pipes As per IS 1239/3589, IS 4270-2001 |
Fire Fighting/HVAC Industries | (Heating Ventilation air conditioning) In MEP, PHE & other Industrial applications IS 1239 (part 1) 2004, IS 3589:2001 ASTM A53-12, ASTM A795-04 |
Construction {RHS/SHA/CHS} | Scaffolding & Structural purposes IS 1161: 2014, IS 4923:2017, EN 39:2001, EN 10219-PART 1& 2: 2006, AS/NZ 1163:2009 ASTM A500-13 |
Gas/Oil Pipe Lines | Pipe lines for natural gas, LPG, PNG And other non-toxic gases IS 1239 (Part 1): 2004, IS/ISO 3183:2007 |
Cement/Sugar/Paper Industries | Steel tubes for mechanical & general Engineering purposes. (IS 3601: 2006, BS 1775: 1964) |
Automobiles | Motorcycles & Car IS 3074: 2013, IS3601:2006, EN10305: 2003 |
Bicycles | IS2039/1991, BS1717 |
Steel/Power Project | Ash handling systems LP piping (IS3589:2001, IS1239 (PART 1): 2004 |
General Engineering | Furniture, barricade, Commercial vehicle body, Supply of exhaust piping, Cold storage industry, LPG cylinder rings, (IS 1239 (PART1):2004 Steel tubes for idlers & belt conveyers (IS 9295:1983) Electrical poles & Telecom tower (IS 1161: 2014) |
Indian Standard | American Standard | British Standard | Japanese Standard | European Standard |
---|---|---|---|---|
IS 1161: 2014 | ASTM A500 | BS 4360 | JIS G3444 : 1994 | EN 10219 |
GR A: 1993 | BS 7613: 1994 | |||
IS 1239 (Part 1): 2004 | ASTM A53/1993 | BS 1387 : 1985 | EN 10255 | |
Elong 20% for all | ||||
Galv. 550Gms/m² | ||||
IS 9295 : 1983 | ASTM A513 | BS 6323 : 1982 | ||
IS 3601 : 2006 | BS 1775 | JIS G3343 : 1983 | EN 10219 | |
BS 6323 : 1982 | ||||
IS 4923 : 2017 | ASTM A500 | BS 6363 | JIS G3466 : 1982 | EN 10219 |
GR A : 1993 | ||||
IS 4270 : 2001 | BS 879 | |||
IS 3589 : 2001 | BS 5534 | |||
IS 9537 : 1981 | BS 4568 |
Nominal Bore (N.B.) | Outside | Diameter | Wall Thickness | Normal Weight Kg. / Meters | Meters / Ton | |||||
---|---|---|---|---|---|---|---|---|---|---|
Minimum | Maximum | |||||||||
MM | INCH | MM | MM | CLASS | MM | SWG | P.E. | S&S | P.E. | S&S |
15 | (1/2") | 21.00 | 21.40 | L | 2.00 | 14 | 0.95 | 0.96 | 1056 | 1046 |
21.00 | 21.80 | M | 2.60 | 12 | 1.21 | 1.22 | 826 | 820 | ||
21.00 | 21.80 | H | 3.20 | 10 | 1.44 | 1.45 | 694 | 690 | ||
20 | (3/4") | 26.40 | 26.90 | L | 2.30 | 13 | 1.38 | 1.39 | 725 | 719 |
26.50 | 27.30 | M | 2.60 | 12 | 1.56 | 1.57 | 641 | 637 | ||
26.50 | 27.30 | H | 3.20 | 10 | 1.87 | 1.88 | 535 | 532 | ||
25 | (1") | 33.20 | 33.80 | L | 2.60 | 12 | 1.98 | 2.00 | 505 | 500 |
33.30 | 34.20 | M | 3.20 | 10 | 2.41 | 2.43 | 415 | 411 | ||
33.30 | 34.20 | H | 4.00 | 8 | 2.93 | 2.95 | 341 | 339 | ||
32 | (1 1/4") | 41.90 | 42.50 | L | 2.60 | 12 | 2.54 | 2.57 | 394 | 389 |
42.00 | 42.90 | M | 3.20 | 10 | 3.10 | 3.13 | 322 | 319 | ||
42.00 | 42.90 | H | 4.00 | 8 | 3.79 | 3.82 | 264 | 262 | ||
40 | (1 1/2") | 47.80 | 48.40 | L | 2.90 | 1 | 3.23 | 3.27 | 310 | 306 |
47.90 | 48.80 | M | 3.20 | 10 | 3.56 | 3.60 | 281 | 278 | ||
47.90 | 48.80 | H | 4.00 | 8 | 4.37 | 4.41 | 229 | 227 | ||
50 | (2") | 59.60 | 60.20 | L | 2.90 | 1 | 4.08 | 4.15 | 245 | 241 |
59.70 | 60.80 | M | 3.60 | 9 | 5.03 | 5.10 | 199 | 196 | ||
59.70 | 60.80 | H | 4.50 | 7 | 6.19 | 6.26 | 161 | 160 | ||
65 | (2 1/2") | 75.20 | 76.00 | L | 3.20 | 10 | 5.71 | 5.83 | 175 | 171.5 |
75.30 | 76.60 | M | 3.60 | 9 | 6.42 | 6.54 | 156 | 153 | ||
75.30 | 76.60 | H | 4.50 | 7 | 7.93 | 8.05 | 126 | 124 | ||
80 | (3") | 87.90 | 88.70 | L | 3.20 | 10 | 6.72 | 6.89 | 149 | 145 |
88.00 | 89.50 | M | 4.00 | 8 | 8.36 | 8.53 | 120 | 117 | ||
88.00 | 89.50 | H | 4.80 | 6 | 9.90 | 10.10 | 101 | 99 | ||
100 | (4") | 113.00 | 113.90 | L | 3.60 | 9 | 9.750 | 10.00 | 102 | 100 |
113.10 | 115.00 | M | 4.50 | 7 | 12.20 | 12.50 | 82 | 80 | ||
113.10 | 115.00 | H | 5.40 | 5 | 14.50 | 14.80 | 69 | 67 | ||
125 | (5") | 138.50 | 140.80 | M | 4.80 | 6 | 15.90 | 16.40 | 63 | 61 |
138.50 | 140.80 | H | 5.40 | 5 | 17.90 | 18.40 | 56 | 54 | ||
150 | (6") | 163.90 | 166.50 | M | 4.80 | 6 | 18.90 | 19.50 | 53 | 51 |
163.90 | 166.50 | H | 5.40 | 5 | 21.30 | 21.90 | 47 | 46 |
Thickness: | Chemical Composition: |
---|---|
|
|
Weight: | Physical Properties: |
---|---|
|
|
SHS (DXB)* | Thickness | Unit Weight | |
---|---|---|---|
MM | MM | Kg/Meter | Meter/Ton |
15 x 15 | 1.20 | 0.49 | 2037 |
1.60 | 0.62 | 1609 | |
2.00 | 0.74 | 1359 | |
19 x 19 | 2.00 | 0.99 | 1013 |
2.60 | 1.20 | 832 | |
2.90 | 1.30 | 772 | |
25 X 25 | 2.00 | 1.36 | 733 |
2.60 | 1.69 | 591 | |
3.20 | 1.98 | 504 | |
32 x 32 | 2.60 | 2.26 | 442 |
3.20 | 2.69 | 372 | |
4.00 | 3.19 | 313 | |
38 x 38 | 2.00 | 2.18 | 459 |
2 .60 | 2.75 | 364 | |
3.20 | 3.29 | 304 | |
4 .00 | 3.95 | 253 | |
40 X 40 | 2.00 | 2.31 | 434 |
2 .60 | 2.92 | 343 | |
3.20 | 3.49 | 286 | |
4 .00 | 4 .20 | 238 | |
49.5 X 49.5 | 2.60 | 3.69 | 271 |
3.20 | 4.45 | 225 | |
4.50 | 5.95 | 168 | |
60 X 60 | 2 .60 | 4.55 | 220 |
3.20 | 5.50 | 182 | |
3.50 | 5.96 | 168 | |
4.50 | 7.43 | 135 | |
72 x 72 | 3.20 | 6.71 | 149 |
4 .00 | 8.22 | 122 | |
5.00 | 10.01 | 100 |
Steel Grade | Min. Yield Stress | Min. UTS |
---|---|---|
MPa | MPa | |
YSt 210 | 210 | 330 |
YSt 240 | 240 | 410 |
YSt 310 | 310 | 450 |
YSt 355 | 355 | 490 |
SHS (DXB)* | Thickness | Unit Weightn | |
---|---|---|---|
MM | MM | Kg/Meter | Meter/Ton |
80 x 80 | 3.20 | 7.51 | 133 |
4.00 | 9.22 | 108 | |
5.00 | 11.27 | 89 | |
91.5x91.5 | 3.60 | 9.67 | 103 |
4.50 | 11.88 | 84 | |
5.40 | 14.01 | 71 | |
100 x 100 | 3.60 | 10.64 | 94 |
4 .50 | 13.08 | 76 | |
6.00 | 16.98 | 59 | |
113.5 x 113.5 | 4.00 | 13.43 | 74 |
5.00 | 16.53 | 60 | |
6.00 | 19.53 | 51 | |
125 x 125 | 4.00 | 14.87 | 67 |
5.00 | 18.33 | 55 | |
6.00 | 21.69 | 46 | |
132 x 132 | 4.00 | 15.75 | 63 |
5.00 | 19.43 | 51 | |
6.00 | 23.01 | 43 | |
150 x 150 | 5.00 | 22.26 | 45 |
6.00 | 26.40 | 38 | |
7.00 | 30.44 | 33 | |
180 x 180 | 5.00 | 26.97 | 37 |
6.00 | 32.05 | 31 | |
8.00 | 41.91 | 24 |
The size which are not covered in the Table can also be supplied as per customer requirement.
Steel Grade | Elongation Percent Min, for Sizes | |
---|---|---|
25.4 and under* | Over 25.4* | |
YSt 210 | 12 | 20 |
YSt 240 | 10 | 15 |
YSt 310 | 8 | 10 |
YSt 355 | 8 | 10 |
*The value shall be applicable for the smaller side of the rectangular section
RHS | Thic kness | UnitWeight | |
---|---|---|---|
MM | MM | Kg/Meter | Meter/Ton |
40 X 20 | 2.00 | 1.68 | 595 |
2.60 | 2.10 | 476 | |
3.20 | 2.49 | 402 | |
40 X 25 | 1.60 | 1.50 | 666 |
2.00 | 1.83 | 545 | |
2.50 | 2.23 | 449 | |
50 x 25 | 2.00 | 2.15 | 465 |
2.60 | 2.71 | 369 | |
3.20 | 3.27 | 309 | |
4.00 | 3.88 | 258 | |
50 X 30 | 2.00 | 2.31 | 434 |
2.50 | 2.82 | 355 | |
2.90 | 3.21 | 312 | |
50 X 40 | 2.00 | 2.62 | 382 |
2.50 | 3.21 | 312 | |
2.90 | 3.66 | 273 | |
60 X 40 | 2.60 | 3.73 | 268 |
3.20 | 4.50 | 222 | |
4.50 | 6.02 | 166 | |
66 X 33 | 2.60 | 3.69 | 271 |
3.20 | 4.45 | 225 | |
4.50 | 5.95 | 168 | |
75 X 25 | 2.60 | 3.73 | 268 |
3.20 | 4.50 | 222 | |
4.50 | 6.02 | 166 | |
80 X 40 | 2.90 | 5.03 | 199 |
3.50 | 5.96 | 168 | |
4.50 | 7.43 | 135 | |
96 x 48 | 3.20 | 6.17 | 149 |
4.00 | 8.22 | 122 | |
5.00 | 10.01 | 100 | |
90 x 60 | 3.20 | 7.01 | 143 |
4.00 | 8.59 | 116 | |
5.00 | 10.48 | 95 | |
100 x 50 | 3.20 | 7.01 | 143 |
4.00 | 8.59 | 116 | |
5.40 | 11.21 | 89 | |
6.00 | 12.27 | 81 | |
120 x 60 | 3.60 | 9.50 | 105 |
4.50 | 11.67 | 86 | |
5.40 | 13.76 | 73 | |
122 x 61 | 3.60 | 9.67 | 103 |
4.50 | 11.88 | 84 | |
5.40 | 14.01 | 71 | |
125 x 75 | 4.00 | 11.73 | 85 |
5.00 | 14.41 | 69 | |
6.00 | 16.98 | 59 | |
125 x 100 | 4.00 | 13.30 | 75 |
5.00 | 16.37 | 61 | |
6.00 | 19.34 | 52 | |
145 x 82 | 3.60 | 12.16 | 82 |
4.50 | 14.99 | 67 | |
5.40 | 17.74 | 56 | |
150 x 75 | 3.60 | 12.05 | 83 |
4.50 | 14.85 | 67 | |
5.40 | 17.57 | 57 |
RHS | Thickness | Unit Weight | |
---|---|---|---|
MM | MM | Kg/Meter | Meter/Ton |
150 x100 | 3.60 | 13.46 | 74 |
4.50 | 16.62 | 60 | |
5.40 | 19.69 | 51 | |
172 x92 | 3.60 | 14.25 | 70 |
4.50 | 17.61 | 57 | |
5.40 | 20.88 | 48 | |
200 x 100 | 4.50 | 20.15 | 50 |
6.00 | 26.40 | 38 | |
7.00 | 30.44 | 33 | |
200 x 150 | 4.50 | 23.68 | 42 |
6.00 | 31.11 | 32 | |
8.00 | 40.66 | 25 |
Spec: | IS 4923: 2017 |
---|---|
Length: | 6.0mtrs. +/- 6.0mm customized length ranging from 4mtrs. to 8mtrs.May be supplied |
Thickness: | For all sizes: +/- 7.5% |
Outer Dimensions: | 1% with a min of 0.5mm |
Corner Squareness: | 90°+/-2° |
Corner Radii: | Max. 3t (t = Thickness of the section) |
Weight: | on individual length:+10%, -8% on lots of 10MT: +/- 7 % |
Straightness: | Min1:600 of any length measured along the center line (mill straightened condition) unless otherwise specifically arranged |
Twist Tolerance: | Max.2mm: +0.5mm/1m length the measured relative vertical shift of any adjacent corner of the measured by keeping one side on flat surface. |
End finish: | Plain Ended - Mechanically sheared, mill-cut finish without further machining. |
Surface Finish: | Black without any surface treatment of oiling or varnishing |
Raw Material: | Sulphur content: 0.040% max; Phosphorus content:0.040% max. |
Remark : Mass Of Zinc Coating Per Galvanized Tube as Per Customers Requirements.
Nominal Size NB | Outside Diameter D | Thickness T | Nominal Weight Back Tubes Plain End | |||
---|---|---|---|---|---|---|
MM | INCH | MM | MM | SWG | Kg/Meter | Meter/Ton |
15 | (1/2") | 21.30 | 2.00 | 14 | 0.952 | 1050 |
2.60 | 12 | 1.200 | 834 | |||
3.20 | 10 | 1.430 | 700 | |||
20 | (3/4") | 26.90 | 2.30 | 13 | 1.400 | 717 |
2.60 | 12 | 1.560 | 642 | |||
3.20 | 10 | 1.870 | 535 | |||
25 | (1") | 33.70 | 2.60 | 12 | 1.990 | 501 |
3.20 | 10 | 2.410 | 415 | |||
4.00 | 08 | 2.930 | 341 | |||
32 | (1/4") | 42.40 | 2.60 | 12 | 2.552 | 392 |
3.20 | 10 | 3.094 | 323 | |||
4.00 | 08 | 3.790 | 264 | |||
40 | (1 1/2") | 48.30 | 2.90 | 11 | 3.250 | 308 |
3.20 | 10 | 3.560 | 281 | |||
4.00 | 08 | 4.370 | 229 | |||
50 | (2") | 60.30 | 2.90 | 11 | 4.110 | 244 |
3.60 | 09 | 5.030 | 199 | |||
4.50 | 07 | 6.190 | 162 | |||
65 | (2 1/2") | 76.10 | 3.20 | 10 | 5.750 | 175 |
3.60 | 09 | 6.440 | 155 | |||
4.50 | 07 | 7.950 | 126 | |||
80 | (3") | 88.90 | 3.20 | 10 | 6.760 | 148 |
4.00 | 08 | 8.380 | 119 | |||
4.80 | 06 | 9.960 | 100 | |||
100 | (4") | 114.30 | 3.60 | 09 | 9.830 | 102 |
4.50 | 07 | 12.190 | 82 | |||
5.40 | 05 | 14.500 | 69 | |||
110 | (4 1/2") | 127.00 | 4.50 | 07 | 13.600 | 74 |
4.80 | 06 | 14.500 | 69 | |||
5.40 | 05 | 16.190 | 62 | |||
125 | (5") | 139.70 | 4.50 | 07 | 15.000 | 67 |
4.80 | 06 | 15.970 | 63 | |||
5.40 | 05 | 17.900 | 56 | |||
135 | (5 1/2") | 152.40 | 4.50 | 07 | 16.400 | 61 |
4.80 | 06 | 17.500 | 57 | |||
5.40 | 05 | 19.600 | 51 | |||
150 | (6") | 165.10 | 4.50 | 07 | 17.800 | 56 |
4.80 | 05 | 18.980 | 53 | |||
5.40 | 05 | 21.300 | 47 | |||
150 | (6") | 168.30 | 4.50 | 07 | 18.200 | 55 |
4.80 | 06 | 19.400 | 52 | |||
5.40 | 05 | 21.700 | 46 | |||
6.30 | 03 | 25.200 | 40 | |||
175 | (7") | 193.70 | 4.80 | 06 | 22.400 | 45 |
5.40 | 05 | 25.100 | 40 | |||
5.90 | 04 | 27.300 | 37 | |||
200 | (8") | 219.10 | 4.80 | 06 | 25.400 | 39 |
5.60 | 05 | 29.500 | 34 |
Chemical Properties | |
---|---|
C | 0.20% Max |
Mn | 1.3% Max |
P | 0.04% Max |
S | 0.04% Max |
Physical Properties | |||
---|---|---|---|
Grade | YS(Min.) MPa | TS(Min.) MPa | % age (Min.) Elong. |
YSt 210 | 210 | 330 | 20 |
CYSt 240 | 240 | 410 | 17 |
YSt 310 | 310 | 450 | 14 |
YSt 355 | 355 | 490 | 10 |
Note: For tubes upto size 25mm NB including Elongation of 12% shall be permissible.
Weight | |
---|---|
Single tubes | +/- 10% |
Weight Truck Load | |
---|---|
For lot of 10 Ton | +/- 7.5% |
Tolerance | |
---|---|
Outside diameter: upto and including 48.3mm |
+ 0.4mm - 0.8mm |
Over 48.3mm | +/- 1% |
Thickness | |
---|---|
+/- 10% |
Mass of Zinc Coating : Min 360 gm/m2
Nominal Size NB | Outside Diameter D | Thickness T | Nominal Weight Back Tubes Plain End | ||
---|---|---|---|---|---|
MM | INCH | MM | MM | Kg/m | Mtr/Tone |
150 | (6'') | 168.30 | 2.60 | 10.60 | 94.30 |
168.30 | 3.20 | 13.03 | 76.75 | ||
168.30 | 4.00 | 16.21 | 61.70 | ||
168.30 | 5.00 | 20.14 | 49.66 | ||
168.30 | 6.00 | 24.01 | 41.64 | ||
168.30 | 7.00 | 27.84 | 35.91 | ||
175 | (7") | 193.70 | 4.00 | 18.71 | 53.44 |
193.70 | 5.00 | 23.27 | 42.97 | ||
193.70 | 6.00 | 27.77 | 36.01 | ||
193.70 | 7.00 | 32.23 | 31.03 | ||
200 | (8") | 219.10 | 2.60 | 13.88 | 72.00 |
219.10 | 3.60 | 19.13 | 52.27 | ||
219.10 | 4.00 | 21.22 | 47.13 | ||
219.10 | 5.00 | 26.40 | 37.88 | ||
219.10 | 5.40 | 28.46 | 35.14 | ||
219.10 | 6.00 | 31.53 | 31.72 | ||
219.10 | 7.00 | 36.61 | 27.31 |
Outside Diameter: | +/- 0.75% of OD |
---|---|
Wall Thickness: | +/- 10% |
Ovality: | Shall not exceed 1 % of the specified diameter |
Bead Height: | The maximum height of the weld bead on the internal surface of the pipes shall not exceed 60% of nominal wall thickness |
Straightness: | Shall not deviate from the straightness by more than 0.2% of total length |
Length: | Single random length of 4 to 7 meter |
Weight: | +/- 7.5% on truck load |
Grade Yield | Stress Tensile | Strength | %Elongation |
---|---|---|---|
MPa (Min) | MPa (Min) | (Min) | |
Fe 330 | 195 | 330 | 20 |
Fe 410 | 235 | 410 | 18 |
Fe 450 | 275 | 450 | 15 |
Outside Diameter | Thickness | Mass |
---|---|---|
MM | MM | M/T |
21.30 | 1.80 2.00 2.60 3.20 |
0.87 0.95 1.20 1.43 |
26.90 | 1.80 2.00 2.30 2.60 3.20 |
1.11 1.23 1.40 1.56 1.87 |
33.70 | 2.00 2.30 2.60 3.20 4.00 |
1.56 1.78 1.99 2.41 2.93 |
42.40 |
2.30 2.60 3.20 3.60 4.00 |
2.27 2.55 3.09 3.44 3.79 |
48.30 | 2.30 2.60 2.90 3.20 3.60 4.00 |
2.61 2.93 3.25 3.56 3.97 4.37 |
60.30 | 2.30 2.60 2.90 3.20 3.60 4.00 4.50 |
3.29 3.70 4.11 4.51 5.03 5.55 6.19 |
76.10 | 2.60 2.90 3.20 3.60 4.50 5.00 |
4.71 5.24 5.75 6.44 7.11 7.95 |
88.90 | 2.90 3.20 4.00 5.00 5.40 5.60 |
6.15 6.76 8.38 10.30 11.10 11.50 |
Outside Diameter | Thickness | Mass |
---|---|---|
MM | MM | M/T |
101.60 | 3.60 4.00 5.00 |
8.70 9.63 11.90 |
114.30 | 3.20 3.60 4.50 5.40 6.30 |
8.77 9.83 12.20 14.50 16.80 |
139.70 | 3.60 4.00 4.50 5.00 5.40 6.30 |
12.10 13.40 15.00 16.60 17.90 20.70 |
152.40 | 4.50 5.00 5.40 |
16.40 18.20 19.60 |
165.10 | 4.50 5.00 5.40 6.30 |
17.80 19.70 21.20 24.80 |
168.30 | 4.50 5.00 5.40 6.30 |
17.80 19.70 21.20 24.80 |
168.30 | 4.00 4.50 5.00 5.40 6.30 7.10 8.00 |
16.20 18.20 20.10 21.70 25.20 28.20 31.60 |
193.70 | 5.00 5.40 5.90 6.30 8.00 |
23.30 25.10 27.30 29.10 36.60 |
219.10 |
4.50 5.00 5.60 6.30 8.00 |
23.80 26.40 29.50 33.10 41.60 |
Grade | Y.S.(Min.) | T.S.(Min) | % age Elongation (Min.) | |
---|---|---|---|---|
(MPa) | (MPa) | As Welded (less than or equal to 33.7 mm OD) | As Welded (more than 33.7 mm OD) | |
WT160 | 160 | 310 | 15 | 22 |
WT210 | 210 | 330 | 12 | 20 |
WT240 | 240 | 410 | 10 | 15 |
WT310 | 310 | 450 | 6 | 10 |
Outside Diameter upto 25.40 mm | +0.15 mm |
---|---|
Outside Diameter upto & including 51 mm | +0.18 mm |
Over 51 mm to 76.10 mm | ±0.25 mm |
Above 76.10 to 88.90 mm | ±0.31 mm |
Above 88.90 to 101.60 mm | ±0.36 mm |
Above 101.60 to 114.3mm | ±0.43 mm |
Above 114.30 to 152.40 mm | ±0.58 mm |
Above 152.40 to 168.30 mm | ±0.65 mm |
Above 168.30 | ±0.75 mm |
Note:
1. Any OD & Thickness not covered in this table may be supplied as per customer requirement
2. The Tolerance of thickness excluding the weld shall be 10%
